T-Line

75BDL3652T/00

Maximise engagement and inspire collaboration with an interactive Philips T-Line display. Featuring anti-glare toughened glass, these Android-powered displays are made to withstand heavy daily usage and feature up to 20 touchpoints

Get a quote

Technical Specifications

Miscellaneous

On-Screen Display Languages	Arabic
	Dutch
	Danish
	English
	French
	Finnish
	German
	Italian
	Japanese
	Norwegian
	Polish
	Portuguese
	Russian
	Spanish
	Swedish
	Simplified Chinese
	Turkish
	Traditional Chinese
Regulatory approvals	CE
	FCC, Class A
	RoHS
	CB
	BSMI
	EAC
	EMF
	PSB
	ETL
Warranty	5-year warranty

Operating conditions

Temperature range (storage)	-20 ~ 60 °C
Relative humidity	20–80% (Operational), 5–95% (Storage) %
Altitude	0 ~ 3000 m
Temperature range (operation)	0 ~ 40 °C
MTBF	50,000 hour(s)

Picture/Display

Diagonal screen size (metric)	189.3 cm
Brightness	420 cd/m²
Panel resolution	3840 x 2160
Pixel pitch	0.4296 x 0.4296 mm
Surface treatment	Anti-Glare coating
Picture enhancement	3/2 - 2/2 motion pull down
	3D Combfilter
	Motion compens. deinterlacing
	Progressive scan
	3D MA deinterlacing
	Dynamic contrast enhancement
Optimum resolution	3840 x 2160 @ 60 Hz
Display colours	1.07 billion
Aspect ratio	16:9
Viewing angle (horizontal)	178 degree
Dynamic contrast ratio	500,000:1
Panel technology	IPS
Response time (typical)	9 ms
Diagonal screen size (inch)	74.5
Contrast ratio (typical)	1200:1
Viewing angle (vertical)	178 degree
Operating system	Android 9

Supported Display Resolution

Video formats	480p, 60 Hz
	576p, 50 Hz
	720p, 60 Hz
	720p, 50, 60 Hz
	1080i, 50, 60 Hz
	1080p, 50, 60 Hz
	4K x 2K
Computer formats	640 x 350, 70 Hz
	640 x 480, 60, 67, 72, 75 Hz
	800 x 600, 56, 60, 72, 75 Hz
	832 x 624, 75 Hz
	848 x 480, 60 Hz
	960 x 720, 75 Hz
	1024 x 768, 60, 70 Hz
	1152 x 864, 60, 70, 75 Hz
	1152 x 900, 66 Hz
	1280 x 720, 60, 70 Hz
	1280 x 768, 60 Hz, 75 Hz
	1280 x 800, 60, 75 Hz
	1280 x 960, 60 Hz
	1280 x 1024, 60, 67, 75 Hz
	1360 x 768, 60 Hz
	1366 x 768, 60 Hz
	1400 x 1050, 60, 75 Hz
	1440 x 900, 60, 75 Hz
	1440 x 1050, 60 Hz
	1600 x 900, 60 Hz
	1600 x 1200, 60 Hz
	1680 x 1050, 60 Hz
	1920 x 1080, 60 Hz
	1920 x 1200, 60 Hz
	3840 x 2160, 24, 25, 30, 60 Hz

Interactivity

Protection glass	Anti-Glare
	Tempered safety glass
Multi-touch technology	0-gap Infrared touch
Plug and play	HID compliant
Touchpoints	20 simultaneous touch points

Connectivity

Video output	DisplayPort 1.2 (x 1)
	DVI - D (x 1)
	HDMI 2.0 (x 2)
	USB 2.0 (x 2)
Audio output	3.5 mm Jack (x 2)
Video input	Display Port1.2 (x 1)
	DVI-I (x 1)
	HDMI 2.0 (x 4)
	USB 2.0 (x 2)
	USB 3.0 (x 2)
	USB-C
Audio input	3.5 mm Jack (x 1)
Other connections	OPS
	micro SD
External control	IR (in/out) 3.5 mm jack
	RJ45
	RS232C (in/out) 2.5 mm jack

Convenience

Ease of installation	Smart Insert
Remote control signal	Lockable
Energy-saving functions	Smart Power
Screen-saving functions	Pixel Shift, Low Brightness
Placement	Portrait (12/7)
	Landscape (18/7)
Picture performance	Advanced colour control
Network controllable	RS232
	RJ45
Other convenience	Carrying handles
Signal loop through	DisplayPort
	RS232
	IR Loop through
Keyboard control	Hidden
	Lockable

Accessories

Optional accessories	Interact dongles
Included Accessories	Cleaning cloth (x 1)
	DVI-D cable (1.8 m)
	M2 Screw (x 2)
	M3 screw (x 2)
	Philips logo (x 1)
	RS232 daisy-chain cable
	Touch Pen (x 2)
	Touch USB (x 1)
	USB Cover (x 1)
	AC power cord
	Batteries for remote control
	HDMI cable
	IR sensor cable (1.8 m) (x 1)
	Quick start guide (x 1)
	Remote control (x 1)
	RS232 cable

Internal Player

Storage	32 GB eMMc
Memory	4 GB RAM
CPU	MTK5680
GPU	DDR4 4 GB
Wi-Fi	AP(WC0SR2511-88112BU)
	STA(WCT5GM2511MT7668AU)

Dimensions

Wall Mount	600(H)x400(V) mm, M8
Set Height	993.70 mm
Set Width	1715.50 mm
Set Width (inch)	67.54
Set Depth	80.8 mm (D@wall mount) / 108.7 mm (D@speaker cover) mm
Set Height (inch)	39.12
Smart Insert mount	100 mm x 100 mm, 6 x M4L6
Product weight (lb)	116.85 lb
Set Depth (inch)	3.18"(D@wall mount) /4.28" (D@speaker cover)
Product weight	53.0 kg
Bezel width	17.8 mm(even)

Sound

Built-in speakers	2 x 20 W RMS

Power

Energy Label Class	G
Consumption (Typical)	190 W
Power Saving Features	Smart Power
Consumption (Max)	380 W
Mains power	100 ~ 240 VAC, 50/60 Hz
Standby power consumption	<0.5 W
