55BDL3550Q/00

55″
Philips Q-Line
Inform and enthrall with a Philips Q-Line Professional 4K Ultra HD Display. This reliable solution can be up and running as quickly as you need.
Q-Line

Versatile signage

Ultimate attention

Q-Line makes your content the focal point in any space.

Features

Technical Specifications

Picture/Display

Diagonal screen size (metric) 138.7
Diagonal screen size (inch) 54.6
Panel resolution 3840 x 2160
Optimum resolution 3840 x 2160 @ 60 Hz
Brightness 400
Contrast ratio (typical) 1300:1
Dynamic contrast ratio 500,000:1
Response time (typical) 9
Aspect ratio 16:9
Viewing angle (horizontal) 178
Viewing angle (vertical) 178
Pixel pitch 0.315 x 0.315 mm
Display colors 1.07 Billion
Clinical image D-Image preset (dicom part 14 compatible)
Operating system Android 8.0
Panel technology IPS
Picture enhancement 3/2 - 2/2 motion pull down
3D Combfilter
3D MA deinterlacing
Dynamic contrast enhancement
Motion compens. deinterlacing
Progressive scan

Supported Display Resolution

Computer formats 1920 x 1080, 60Hz
1600 x 1200, 60Hz
1440 x 900, 60Hz
1280 x 1024, 60Hz
1280 x 720, 60Hz
1280 x 800, 60Hz
1024 x 768, 60, 70, 75Hz
720 x 400, 70Hz
640 x 480, 60, 67, 72, 75Hz
1152 x 870, 75Hz
1680 x 1050, 60Hz
800 x 600, 56, 60, 72, 75Hz
1152 x 864, 75Hz
832 x 624, 75Hz
Video formats 3840 x 2160, 60Hz
3840 x 2160, 30Hz
480i, 60Hz
480p, 60Hz
576i, 50Hz
576p, 50Hz
1080p, 50, 60Hz
1080i, 50, 60Hz
720p, 50,60 Hz

Connectivity

Video input DVI-D (x1)
HDMI 2.0 (x2)
USB 2.0 (x2)
VGA (Analog D-Sub) (x1)
Audio input 3.5 mm jack
Audio output 3.5mm jack
External control RJ45
RS232C (in/out) 2.5 mm jack
IR (in/out) 3.5 mm jack

Convenience

Energy saving functions Smart Power
Tiled Matrix Up to 15 x 15
Start-up Switch on delay
Switch on status
Boot on source
Start-up window enable / disable Philips logo
Keyboard control Lockable
Hidden
Network controllable RS232
RJ45
Signal loop through RS232
IR Loopthrough
Placement Landscape (18/7)
Portrait (18/7)
Remote control signal Lockable

Dimensions

Bezel width 13.9 mm (Even bezel)
Set Width 1241.8
Set Height 712.6
Set Depth 63.6
Set Width (inch) 48.89
Set Height (inch) 28.06
Set Depth (inch) 2.50
VESA Mount 400mm x 400mm , M6
Product weight 16.6
Product weight (lb) 36.60

Operating conditions

Temperature range (operation) 0 ~ 40
Temperature range (storage) -20 ~ 60
MTBF 50,000
Humidity range (operation)[RH] 20 ~ 80% RH (No condensation)
Humidity range (storage) [RH] 5 ~ 95% RH (No condensation)
Altitude 0 ~ 3000 m

Power

Mains power 100 ~ 240 VAC
Standby power consumption <0.5 W
Consumption (Max) 175 W
Consumption (Typical) 125
Power Saving Features Smart Power
Energy Label Class G

Sound

Built-in speakers 2 x 10W RMS

Multimedia Applications

USB Playback Video MPEG
H.264
H.263
H.265
USB Playback Picture JPEG
BMP
PNG
USB Playback Audio AAC
HEAAC
MPEG

Accessories

Included accessories AC Power Cord
RS232 cable
Remote Control
Batteries for remote control
Quick start guide
Included Accessories IR sensor cable (1.8 m) (x1)
RS232 daisy-chain cable
Philips logo (x1)
USB Cover and screw (x2)
Stand BM05922(optional)

Miscellaneous

Warranty 3 year warranty
On-Screen Display Languages English
French
German
Italian
Polish
Turkish
Russian
Simplified Chinese
Spanish
Traditional Chinese
Arabic
Japanese
Regulatory approvals CE
CB
BSMI
CU
EPA
ETL
FCC, Class A
PSB
VCCI
J-Moss

Internal Player

CPU Dual core cortex A53 1.1G Hz
Dual core cortex A73 1.15G Hz
GPU ARM Mali G51
Memory 2GB DDR3
8GB
