Q-Line

32BDL3511Q/00

Energy Label: g

Inform and enthrall with a Philips Q-Line Professional Fulll HD Display. This reliable solution can be up and running as quickly as you need.

Technical Specifications

Connectivity

Audio output	3.5mm jack
Video input	DVI-I (x 1)
	HDMI 2.0 (x2)
	USB 2.0 (x2)
Audio input	3.5 mm jack
External control	IR (in/out) 3.5 mm jack
	RJ45
	RS232C (in/out) 2.5 mm jack

Convenience

Network controllable	RS232
	RJ45
Tiled Matrix	Up to 10 x 15
Start-up window	enable / disable Philips logo
Energy saving functions	Smart Power
Start-up	Switch on delay
	Switch on status
	Boot on source
Signal loop through	RS232
	IR Loopthrough
Placement	Landscape (18/7)
	Portrait (18/7)
Keyboard control	Hidden
	Lockable
Remote control signal	Lockable

Accessories

Stand	BM02541/BM05911(optional)
Included Accessories	AC Switch Cover
	IR sensor cable (1.8 m) (x1)
	Philips logo (x1)
	Quick start guide (x1)
	Remote control & AAA batteries
	RS232 daisy chain cable (x1)
	USB Cover and screw x1
	Wire Clamper (x3)
	AC power cord

Dimensions

Bezel width	11.9 (TLR) / 17.2 (B) mm
Set Width (inch)	28.6 inch
Set Depth	69.1(D@Handle) / 65.1(D@Wall mount) mm
Set Width	726.5 mm
Product weight	5.7 kg
Set Height	425.4 mm
Wall Mount	100mm x100mm, 200mm x 200mm ,M4
Set Depth (inch)	2.72 (D@Handle) / 2.56 (D@Wall mount) inch
Product weight (lb)	12.57 lb
Set Height (inch)	16.75 inch

Sound

Built-in speakers	2 x 10W RMS

Power

Consumption (Max)	65 W
Power Saving Features	Smart Power
Standby power consumption	<0.5 W
Mains power	100 - 240V~, 50/60Hz
Consumption (Typical)	45 W
Energy Label Class	G

Multimedia Applications

USB Playback Audio	AAC
	WMA
	MPEG
	HEAAC
USB Playback Picture	BMP
	JPEG
	PNG
USB Playback Video	H.264
	JPEG
	MPEG
	WMV3

Miscellaneous

On-Screen Display Languages	Arabic
	English
	French
	German
	Italian
	Japanese
	Polish
	Russian
	Spanish
	Simplified Chinese
	Turkish
	Traditional Chinese
Warranty	3 year warranty
Regulatory approvals	CE
	FCC, Class A
	CB
	EMF
	VCCI
	PSB
	CU
	ETL

Operating conditions

Temperature range (operation)	0 ~ 40 °C
Humidity range (storage) [RH]	5 ~ 95% RH (No condensation)
Altitude	0 ~ 3000 m
Humidity range (operation)[RH]	20 ~ 80% RH (No condensation)
MTBF	50,000 hour(s)
Temperature range (storage)	-20 ~ 60 °C

Picture/Display

Pixel pitch	0.36375 x 0.36375 mm
Panel technology	VA
Viewing angle (horizontal)	178 degree
Panel resolution	1920x1080p
Haze	2%
Dynamic contrast ratio	500,000:1
Aspect ratio	16:9
Optimum resolution	1920 x 1080 @ 60 Hz
Diagonal screen size (inch)	31.5 inch
Diagonal screen size (metric)	80 cm
Display colors	16.7 Million
Clinical image	D-Image preset (dicom part 14 compatible)
Brightness	350 cd/m²
Viewing angle (vertical)	178 degree
Response time (typical)	6.5 ms
Contrast ratio (typical)	4000:1

Supported Display Resolution

Computer formats	640 x 480, 60, 67, 72, 75Hz
	720 x 400, 70Hz
	800 x 600, 56, 60, 72, 75Hz
	832 x 624, 75Hz
	1024 x 768, 60, 70, 75Hz
	1152 x 864, 75Hz
	1152 x 870, 75Hz
	1280 x 720, 60Hz
	1280 x 800, 60Hz
	1280 x 1024, 60Hz
	1440 x 900, 60Hz
	1600 x 1200, 60Hz
	1680 x 1050, 60Hz
	1920 x 1080, 60Hz
Video formats	480i, 60Hz
	480p, 60Hz
	576p, 50Hz
	576i, 50Hz
	720p, 60Hz
	1080i, 50, 60Hz
	1080p, 50, 60Hz
