D-Line
Make it stand out with a fast Philips D-Line Professional 4K UHD display. Philips superb picture quality ensures true colors and intense contrast. You can effortlessly display content from multiple sources on a single screen.
Features
Technical Specifications
Picture/Display
| Diagonal screen size (metric) | 108.0 |
|---|---|
| Diagonal screen size (inch) | 42.5 |
| Panel resolution | 3840 x 2160 |
| Optimum resolution | 3840 x 2160 @ 60Hz |
| Brightness | 500 |
| Dynamic contrast ratio | 500,000:1 |
| Response time (typical) | 8 |
| Aspect ratio | 16:9 |
| Viewing angle (horizontal) | 178 |
| Viewing angle (vertical) | 178 |
| Pixel pitch | 0.2451 x 0.2451 mm |
| Display colors | 1.07 Billion |
| Panel technology | ADS |
| Contrast ratio (typical) | 1200:1 |
| Haze | 25% |
Supported Display Resolution
| Computer formats | 640 x 480, 60Hz |
|---|---|
| 800 x 600, 60Hz | |
| 1024 x 768, 60Hz | |
| 1280 x 720, 60Hz | |
| 1280 x 1024, 60Hz | |
| 1440 x 900, 60 Hz | |
| 1600 x 900, 60Hz | |
| 1680 x 1050, 60Hz | |
| 1920 x 1080, 60Hz | |
| 3840 x 2160, 30, 60Hz | |
| Video formats | 480i, 60Hz |
| 480p, 60Hz | |
| 576p, 50Hz | |
| 576i, 50Hz | |
| 720p, 50,60 Hz | |
| 1080i, 50, 60Hz | |
| 1080p, 50, 60Hz | |
| 2160p, 24, 30, 60Hz |
Connectivity
| Video input | Display Port1.2 (x1) |
|---|---|
| DVI-I (x 1) | |
| HDMI 2.0 (x2) | |
| USB 2.0 (x2) | |
| Audio input | 3.5 mm jack |
| Video output | DisplayPort 1.2 (x1) |
| HDMI 2.0 (x1) | |
| Audio output | 3.5mm jack |
| External control | IR (in/out) 3.5 mm jack |
| RJ45 | |
| RS232C (in/out) 2.5 mm jack | |
| Other connections | OPS |
Convenience
| Placement | Landscape (24/7) |
|---|---|
| Portrait (24/7) | |
| Screen saving functions | Pixel Shift, Low Bright |
| Signal loop through | DisplayPort |
| RS232 | |
| HDMI | |
| IR Loopthrough | |
| Energy saving functions | Smart Power |
| Network controllable | RS232 |
| RJ45 | |
| Keyboard control | Hidden |
| Lockable |
Operating conditions
| Temperature range (operation) | 0 ~ 40 |
|---|---|
| Temperature range (storage) | -20 ~ 60 |
| Altitude | 0 ~ 3000 m |
| MTBF | 50,000 |
| Humidity range (operation)[RH] | 20 - 80% RH (No condensation) |
| Humidity range (storage) [RH] | 5 - 95% RH (No condensation) |
Power
| Consumption (Typical) | 62 |
|---|---|
| Consumption (Max) | 170 W |
| Standby power consumption | 0.5 W |
| Mains power | 100 ~ 240 VAC, 50 ~ 60 Hz |
| Energy Label Class | G |
Sound
| Built-in speakers | 2 x 10W RMS |
|---|
Accessories
| Stand | BM05922(Optional) |
|---|---|
| Included Accessories | AC Switch Cover |
| Philips logo (x1) | |
| RS232 daisy-chain cable | |
| AC power cord | |
| IR sensor cable (1.8 m) (x1) | |
| Quick start guide (x1) | |
| Remote control & AAA batteries | |
| RS232 cable | |
| USB Cover and screw x1 | |
| Wire Clamper (x3) |
Miscellaneous
| On-Screen Display Languages | Arabic |
|---|---|
| Dutch | |
| Danish | |
| English | |
| French | |
| Finnish | |
| German | |
| Italian | |
| Japanese | |
| Norwegian | |
| Polish | |
| Portuguese | |
| Russian | |
| Spanish | |
| Swedish | |
| Simplified Chinese | |
| Turkish | |
| Traditional Chinese | |
| Regulatory approvals | CE |
| FCC, Class A | |
| CCC | |
| RoHS | |
| CB | |
| BSMI | |
| EMF | |
| VCCI | |
| PSB | |
| ETL | |
| CECP | |
| EAC | |
| EnergyStar 8.0 | |
| Warranty | 3 year warranty |
Multimedia Applications
| USB Playback Video | H.263 |
|---|---|
| H.264 | |
| H.265 | |
| MPEG | |
| USB Playback Picture | BMP |
| JPEG | |
| PNG | |
| USB Playback Audio | AAC |
| MPEG | |
| HEAAC |
Dimensions
| Set Width | 973.0 |
|---|---|
| Set Height | 561.2 |
| Set Depth | 63.5 |
| Set Width (inch) | 38.31 |
| Set Height (inch) | 22.09 |
| Set Depth (inch) | 2.50 |
| Bezel width | 13.9 mm (Even bezel) |
| Wall Mount | 200 (H) x 200(V) mm, M6 |
| Product weight | 10.71 |
| Product weight (lb) | 23.61 |
