D-Line
Make it stand out with a fast Philips D-Line Professional 4K UHD display. Philips superb picture quality ensures true colors and intense contrast. You can effortlessly display content from multiple sources on a single screen.
TAA compliant
Created in 1979, TAA compliance requires products and goods considered for governmental use to be manufactured or substantially transformed in the US or in designated TAA countries*. Products for government use are available via selected commercial companies – such as distributors – with Federal Supply Schedule government contracts.
Features
Technical Specifications
Picture/Display
| Diagonal screen size (metric) | 108.0 |
|---|---|
| Diagonal screen size (inch) | 42.5 |
| Panel resolution | 3840 x 2160 |
| Optimum resolution | 3840 x 2160 @ 60Hz |
| Brightness | 500 |
| Dynamic contrast ratio | 500,000:1 |
| Response time (typical) | 8 |
| Aspect ratio | 16:9 |
| Viewing angle (horizontal) | 178 |
| Viewing angle (vertical) | 178 |
| Pixel pitch | 0.2451 x 0.2451 mm |
| Display colors | 1.07 Billion |
| Panel technology | ADS |
| Contrast ratio (typical) | 1200:1 |
| Haze | 25% |
Supported Display Resolution
| Computer formats | 640 x 480, 60Hz |
|---|---|
| 800 x 600, 60Hz | |
| 1024 x 768, 60Hz | |
| 1280 x 720, 60Hz | |
| 1280 x 1024, 60Hz | |
| 1440 x 900, 60 Hz | |
| 1600 x 900, 60Hz | |
| 1680 x 1050, 60Hz | |
| 1920 x 1080, 60Hz | |
| 3840 x 2160, 30, 60Hz | |
| Video formats | 480i, 60Hz |
| 480p, 60Hz | |
| 576p, 50Hz | |
| 576i, 50Hz | |
| 720p, 50,60 Hz | |
| 1080i, 50, 60Hz | |
| 1080p, 50, 60Hz | |
| 2160p, 24, 30, 60Hz |
Connectivity
| Video input | Display Port1.2 (x1) |
|---|---|
| DVI-I (x 1) | |
| HDMI 2.0 (x2) | |
| USB 2.0 (x2) | |
| Audio input | 3.5 mm jack |
| Video output | DisplayPort 1.2 (x1) |
| HDMI 2.0 (x1) | |
| Audio output | 3.5mm jack |
| External control | IR (in/out) 3.5 mm jack |
| RJ45 | |
| RS232C (in/out) 2.5 mm jack | |
| Other connections | OPS |
Convenience
| Placement | Landscape (24/7) |
|---|---|
| Portrait (24/7) | |
| Screen saving functions | Pixel Shift, Low Bright |
| Signal loop through | DisplayPort |
| RS232 | |
| HDMI | |
| IR Loopthrough | |
| Energy saving functions | Smart Power |
| Network controllable | RS232 |
| RJ45 | |
| Keyboard control | Hidden |
| Lockable |
Operating conditions
| Temperature range (operation) | 0 ~ 40 |
|---|---|
| Temperature range (storage) | -20 ~ 60 |
| Altitude | 0 ~ 3000 m |
| MTBF | 50,000 |
| Humidity range (operation)[RH] | 20 - 80% RH (No condensation) |
| Humidity range (storage) [RH] | 5 - 95% RH (No condensation) |
Power
| Consumption (Typical) | 62 |
|---|---|
| Consumption (Max) | 170 W |
| Standby power consumption | 0.5 W |
| Mains power | 100 ~ 240 VAC, 50 ~ 60 Hz |
| Energy Label Class | G |
Sound
| Built-in speakers | 2 x 10W RMS |
|---|
Accessories
| Stand | BM05922(Optional) |
|---|---|
| Included Accessories | AC Switch Cover |
| Philips logo (x1) | |
| RS232 daisy-chain cable | |
| AC power cord | |
| IR sensor cable (1.8 m) (x1) | |
| Quick start guide (x1) | |
| Remote control & AAA batteries | |
| RS232 cable | |
| USB Cover and screw x1 | |
| Wire Clamper (x3) |
Miscellaneous
| On-Screen Display Languages | Arabic |
|---|---|
| Dutch | |
| Danish | |
| English | |
| French | |
| Finnish | |
| German | |
| Italian | |
| Japanese | |
| Norwegian | |
| Polish | |
| Portuguese | |
| Russian | |
| Spanish | |
| Swedish | |
| Simplified Chinese | |
| Turkish | |
| Traditional Chinese | |
| Regulatory approvals | CE |
| FCC, Class A | |
| CCC | |
| RoHS | |
| CB | |
| BSMI | |
| EMF | |
| VCCI | |
| PSB | |
| ETL | |
| CECP | |
| EAC | |
| EnergyStar 8.0 | |
| Warranty | 3 year warranty |
Multimedia Applications
| USB Playback Video | H.263 |
|---|---|
| H.264 | |
| H.265 | |
| MPEG | |
| USB Playback Picture | BMP |
| JPEG | |
| PNG | |
| USB Playback Audio | AAC |
| MPEG | |
| HEAAC |
Dimensions
| Set Width | 973.0 |
|---|---|
| Set Height | 561.2 |
| Set Depth | 63.5 |
| Set Width (inch) | 38.31 |
| Set Height (inch) | 22.09 |
| Set Depth (inch) | 2.50 |
| Bezel width | 13.9 mm (Even bezel) |
| Wall Mount | 200 (H) x 200(V) mm, M6 |
| Product weight | 10.71 |
| Product weight (lb) | 23.61 |
