D-Line

86BDL4650D/00

Philips D-Line is designed to engage your audience and delight customers. Powered by Android 11 for easy software integrations, this versatile display is suitable for impact in any setting.

Get a quote

Technical Specifications

Connectivity

WiFi	WiFi 6 + Bluetooth 5.2 (slide-in module)
Other connections	4G/LTE antenna connectors
	Micro USB (x1) (OTG)
	USB 2.0 (x1)
Audio output	3.5mm jack
Video input	DVI-I (x 1)
	DisplayPort 1.4 (x1)
	HDMI 2.0 (x2)
	USB 3.0 (x2)
	VGA (via DVI)
Audio input	3.5 mm jack
Video output	DisplayPort 1.4 (x1)
External control	RJ45
	RS232C (in/out) 2.5 mm jack
	IR (in/out) 3.5 mm jack

Convenience

Tiled Matrix	Up to 10 x 15
Screen saving functions	Pixel Shift
Energy saving functions	Smart Power
WiFi protocol	a b g n, 802.11 ax, 802.11 ac
Signal loop through	IR Loopthrough
	DisplayPort
	RS232
Keyboard control	Hidden
	Lockable
Network controllable	RS232
	External 4G mPCIe slot
	RJ45
	WiFi
Placement	Landscape (24/7)
	Portrait (24/7)

Accessories

Included Accessories	RS232 daisy-chain cable
	Philips logo (x1)
	AC Switch Cover
	USB Cover (x1)
	Screws
	AC Power Cord
	IR sensor cable (1.8 m) (x1)
	Quick start guide
	Remote control & AAA batteries
	RS232 cable
	WiFi module
	Wire Clamper (x3)

Dimensions

Set Width	1929.0 mm
Set Height	1100 mm
Product weight	50.4 kg
Wall Mount	600(H)x400(V) mm, M8
Set Depth (inch)	2.74(D@Wall mount) / 3.61(D@Handle) inch
Product weight (lb)	111.11 lb
Set Depth	69.5(D@Wall mount) /91.8(D@Handle) mm
Set Width (inch)	75.94 inch
Bezel width	15.5 mm (Even bezel)
Set Height (inch)	43.31 inch

Internal Player

Memory	4GB RAM
Storage	32 GB eMMc
GPU	ARM Mali-T860 MP4
CPU	2x A72 + 4x A53

Sound

Built-in speakers	2 x 10W RMS

Power

Standby power consumption	<0.5 W
Consumption (Typical)	250 W
Mains power	100 ~ 240 VAC, 50 ~ 60 Hz
Energy Label Class	G

Multimedia Applications

USB Playback Video	MPEG
	H.263
	H.264
	H.265
	AVI
	MP4
	MPEG4
	VP8
	VP9
	WEBM
USB Playback Picture	BMP
	JPEG
	PNG
USB Playback Audio	AAC
	HEAAC
	MPEG

Operating conditions

Altitude	0 ~ 3000 m
MTBF	50,000 hour(s)
Humidity range (storage) [RH]	5 - 95% RH (No condensation)
Humidity range (operation)[RH]	20 - 80% RH (No condensation)
Temperature range (storage)	-20 ~ 60 °C
Temperature range (operation)	0 ~ 40 °C

Miscellaneous

On-Screen Display Languages	English
	French
	German
	Spanish
	Polish
	Turkish
	Russian
	Italian
	Simplified Chinese
	Traditional Chinese
	Arabic
	Japanese
	Danish
	Dutch
	Finnish
	Norwegian
	Portuguese
	Swedish
Warranty	3 year warranty
Regulatory approvals	CE
	RoHS
	CB
	CCC
	EMF
	FCC, Class A
	EnergyStar 8.0
	UL

Picture/Display

Picture enhancement	3/2 - 2/2 motion pull down
	Motion compens. deinterlacing
	Dynamic contrast enhancement
	Progressive scan
Response time (typical)	8 ms
Contrast ratio (typical)	1200:1
Viewing angle (horizontal)	178 degree
Viewing angle (vertical)	178 degree
Haze	25%
Optimum resolution	3840 x 2160 @60 Hz
Diagonal screen size (inch)	85.6 inch
Aspect ratio	16:9
Operating system	Android 11
Dynamic contrast ratio	500,000:1
Panel resolution	3840 x 2160
Display colors	1.07 Billion
Diagonal screen size (metric)	217.4 cm
Brightness	500 cd/m²
Panel technology	ADS
Pixel pitch	0.4935 x 0.4935 mm

Supported Display Resolution

Computer formats	1920 x 1080, 60Hz
	1280 x 1024, 60Hz
	1024 x 768, 60Hz
	1280 x 720, 60Hz
	1440 x 900, 60 Hz
	1600 x 900, 60Hz
	1680 x 1050, 60Hz
	3840 x 2160, 30, 60Hz
	640 x 480, 60Hz
	800 x 600, 60Hz
Video formats	1080p, 50, 60Hz
	1080i, 50, 60Hz
	480i, 60Hz
	480p, 60Hz
	576i, 50Hz
	576p, 50Hz
	720p, 50,60 Hz
	2160p, 50, 60Hz
