T-Line

32BDL3751T/00

Delivering 24/7 operation with 350 nits brightness, this versatile PCAP display is also designed to reduce energy consumption across the range. Engage. Inspire. Connect. With Android 13, Wave ready, and no need for an external media player.

Get a quote

Technical Specifications

Miscellaneous

On-Screen Display Languages	Arabic
	English
	French
	German
	Italian
	Japanese
	Polish
	Spanish
	Turkish
	Russian
	Simplified Chinese
	Traditional Chinese
	Danish
	Dutch
	Finnish
	Norwegian
	Portuguese
	Swedish
Warranty	3 year warranty
Regulatory approvals	CB
	CE
	FCC, Class A
	RoHS
	BSMI
	CU
	ETL
	IMDA
	PSB
	EnergyStar 8.0

Weight

Product with packaging (kg)	10.75 kg
Product with packaging (lb)	23.70 lb
Product without packaging (kg)	8.31 kg
Product without packaging (lb)	18.32 lb

Operating conditions

Temperature range (operation)	0 ~ 40 °C
Humidity range (storage) [RH]	5 ~ 95% (without condensation)
Humidity range (operation)[RH]	20 ~ 80% (without condensation)
Altitude	0 ~ 3000 m
MTBF	50,000 hour(s)
Temperature range (storage)	-20~60 °C

Picture/Display

Pixel pitch	0.364 mm
Panel technology	IPS
Viewing angle (horizontal)	178 degree
Panel resolution	1920x1080p
Surface treatments	Anti-Glare coating
	Anti-Fingerprint coating
Brightness (before glass)	400 cd/m²
Aspect ratio	16:9
Operating system	Android 13
Brightness (after glass)	350 cd/m²
Optimum resolution	1920 x 1080 @ 60 Hz
Diagonal screen size (inch)	31.5" inch
OS UI resolution	FHD
Diagonal screen size (metric)	80 cm
Display colors	16.7 M
Response time (typical)	8 ms
Picture enhancement	3/2 - 2/2 motion pull down
	3D Combfilter
	3D MA deinterlacing
	Dynamic contrast enhancement
	Motion compens. deinterlacing
	Progressive scan
Viewing angle (vertical)	178 degree
Contrast ratio (typical)	1200:1

Supported Display Resolution

Computer formats	720 x 400, 70Hz
	640 x 480, 60,67,75Hz
	800 x 600, 60Hz
	832 x 624, 75Hz
	1024 x 768, 60Hz
	1152 x 870, 75Hz
	1280 x 720, 60Hz
	1920 x 1080, 60Hz
	1680 x 1050, 60Hz
	3840 x 2160, 30, 60Hz
Video formats	480i, 60Hz
	480p, 60Hz
	576p, 50Hz
	576i, 50Hz
	720p, 50, 60Hz
	1080i, 50, 60Hz
	1080p, 50, 60Hz
	3840 x 2160, 30, 60Hz

Interactivity

Plug and play	HID compliant
Multi-touch technology	Projected capacitive
Protection glass	2 mm tempered safety glass
Touch points	10 simultaneous touch points

Connectivity

Audio output	3.5mm jack
Video input	HDMI 2.0 (x2)
	Display Port1.3 (x1)
	USB-C (with 15W power delivery)
Other connections	Micro USB (x1) (OTG)
	USB 3.0 A (x2)
	USB 3.0 B (x1)
	Wifi: 2T/2R 2.4/5/6 GHz
	Bluetooth 5.2
External control	Gigabit LAN RJ45
	IR (in/out) 3.5 mm jack
	RS232 (in/out) 2.5 mm jack

Convenience

Network controllable	RS232
	RJ45
Screen saving functions	Pixel Shift, Low Brightness
Remote control signal	Lockable
Placement	Landscape (24/7)
	Portrait (24/7)
	Tilted installation up to 30° backwards
Signal loop through	IR Loopthrough
	RS232
Keyboard control	Hidden
	Lockable

Accessories

Stand	BM05911 (Optional)
Included Accessories	Philips logo (x1)
	Power supply cable (3 m)
	Quick start guide (x1)
	Remote control & AAA batteries
	RS232 cable (3 m) (x1)
	USB A to B cable (3m) (x1)
Optional accessories	Open frame kit (BM03752)

Internal Player

Memory	4GB DDR3
Storage	32 GB eMMc
GPU	Multi-Core Mali-G52
CPU	Quad Core Cortex A55

Dimensions

Set Depth	69.5 mm (Wall mount) / 73.5 mm (AC connector) mm
Bezel width	24.4 mm touch black border (T/R/L/B)
Set Width (inch)	29.49" inch
Set Height	443.6 mm
Set Width	749.1 mm
Wall Mount	100mm x 100mm, 200mm x 200mm , M4
Set Depth (inch)	2.74" (Wall mount) / 2.89" (AC connector) inch
Set Height (inch)	17.46" inch

Sound

Built-in speakers	2 x 10W

Power

Consumption (Max)	87 W
Standby power consumption	<0.5W
Mains power	100 ~ 240 VAC, 50/60Hz
Consumption (Typical)	35 W
Energy Label Class	G

Multimedia Applications

USB Playback Audio	AAC
	HEAAC
	MPEG 1/2/2.5 Layer 3
	MPEG 1/2 Layer 1
	MPEG 1/2 Layer 2
USB Playback Picture	JPEG
	PNG
	BMP
	WEBP
USB Playback Video	MPEG 1/2 (1080p 60Hz)
	MPEG 4 (1080p 60Hz)
	H.263 (1080p 60Hz)
	H.264 (4K2K 120Hz)
	H.265 (4K2K 120Hz)
	VP8 (1080p 60Hz)
	VP9 (4K2K 120Hz)
