E-Line
Inspire collaboration. Maximise engagement. This top-spec Philips E-Line touch display is powered by Android and features enhanced educational software and programs compatibility, 20 touchpoints and a toughened anti-glare glass.
Harness the full power of this display
This product is Wave ready. Giving you the opportunity to manage your Philips professional display remotely and unlocking its full potential – combining energy, time and cost savings, powerful in-house and partner apps, and intuitive content creation – all with PPDS Wave.
Features
Technical Specifications
Picture/Display
| Diagonal screen size (metric) | 163.9 |
|---|---|
| Diagonal screen size (inch) | 64.5 |
| Panel resolution | 3840 x 2160 |
| Optimum resolution | 3840 x 2160 @ 60 Hz |
| Dynamic contrast ratio | 500,000:1 |
| Response time (typical) | 8 |
| Aspect ratio | 16:9 |
| Viewing angle (horizontal) | 178 |
| Viewing angle (vertical) | 178 |
| Pixel pitch | 0.372 x 0.372 mm |
| Display colours | 1.07 Billion |
| Picture enhancement | 3/2 - 2/2 motion pull down |
| 3D Combfilter | |
| Motion compens. deinterlacing | |
| Progressive scan | |
| 3D MA deinterlacing | |
| Dynamic contrast enhancement | |
| Panel technology | ADS |
| Contrast ratio (typical) | 1200:1 |
| Operating system | Android 10 |
| OS UI resolution | 3840 x 2160 @ 60 Hz |
| Brightness (after glass) | 360 |
| Brightness (before glass) | 390 |
Supported Display Resolution
| Computer formats | 640 x 350, 70 Hz |
|---|---|
| 640 x 480, 60, 67, 72, 75 Hz | |
| 800 x 600, 56, 60, 72, 75 Hz | |
| 832 x 624, 75 Hz | |
| 848 x 480, 60 Hz | |
| 960 x 720, 75 Hz | |
| 1024 x 768, 60, 70 Hz | |
| 1152 x 864, 60, 70, 75 Hz | |
| 1152 x 900, 66 Hz | |
| 1280 x 720, 60, 70 Hz | |
| 1280 x 768, 60 Hz, 75 Hz | |
| 1280 x 800, 60, 75 Hz | |
| 1280 x 960, 60 Hz | |
| 1280 x 1024, 60, 67, 75 Hz | |
| 1360 x 768, 60 Hz | |
| 1366 x 768, 60 Hz | |
| 1400 x 1050, 60, 75 Hz | |
| 1600 x 900, 60 Hz | |
| 1600 x 1200, 60 Hz | |
| 1680 x 1050, 60 Hz | |
| 1920 x 1080, 60 Hz | |
| 1920 x 1200, 60 Hz | |
| 3840 x 2160, 24, 25, 30, 60 Hz | |
| 1440 x 900, 60 Hz | |
| 720 x 400, 70 Hz | |
| Video formats | 480p, 60 Hz |
| 720p, 50, 60 Hz | |
| 1080i, 50, 60 Hz | |
| 1080p, 50, 60 Hz | |
| 2160p, 50, 60 Hz | |
| 480i, 60 Hz |
Connectivity
| Video input | DVI-D (x 1) |
|---|---|
| HDMI 2.0 (x 3) | |
| USB 2.0 (x 3) | |
| USB 3.0 (x 3) | |
| USB-C (up to 65 W) | |
| Audio input | 3.5 mm mini jack (x 1) |
| Video output | HDMI 2.0 (x 1) |
| Audio output | 3.5 mm Mini Jack (x 1) |
| External control | IR (in/out) 3.5 mm jack |
| RJ45 | |
| RS232C (in/out) 2.5 mm jack | |
| Other connections | OPS |
| micro SD | |
| USB-B (x 3) |
Convenience
| Placement | Landscape (18/7) |
|---|---|
| Screen-saving functions | Pixel Shift, Low Brightness |
| Signal loop through | RS232 |
| IR Loop through | |
| Ease of installation | Smart Insert |
| AC Out | |
| Network controllable | RS232 |
| RJ45 | |
| Keyboard control | Lockable |
| Remote control signal | Lockable |
| Other convenience | Carrying handles |
Operating conditions
| Temperature range (operation) | 0 ~ 40 |
|---|---|
| Temperature range (storage) | -20 ~ 60 |
| Altitude | 0 ~ 3000 m |
| MTBF | 50,000 |
| Humidity range (operation)[RH] | 20–80% (without condensation) |
| Humidity range (storage) [RH] | 5–95% (without condensation) |
Power
| Consumption (Typical) | 170 |
|---|---|
| Consumption (Max) | 430 W |
| Standby power consumption | <0.5 W |
| Mains power | 100 ~ 240 VAC, 50 ~ 60 Hz |
| Power Saving Features | Smart Power |
| Energy Label Class | G |
Sound
| Built-in speakers | 2 x 15 W |
|---|
Accessories
| Included Accessories | Cleaning cloth (x 1) |
|---|---|
| AC Power Cord | |
| AC Switch Cover | |
| Cable clip (x 3) | |
| DVI-I Cable (1.8 m) (x 1) | |
| HDMI Cable (3 m) (x 1) | |
| IR sensor cable (1.8 m) (x 1) | |
| Philips logo (x 1) | |
| Quick start guide (x 1) | |
| Remote control and AAA batteries | |
| RS232 cable | |
| RS232 daisy chain cable (x 1) | |
| Touch Pen (x 2) | |
| USB A to B cable (3 m) (x 1) | |
| USB cover and screws | |
| Optional accessories | Interact dongles |
Miscellaneous
| On-Screen Display Languages | Arabic |
|---|---|
| Dutch | |
| Danish | |
| English | |
| French | |
| Finnish | |
| German | |
| Italian | |
| Japanese | |
| Norwegian | |
| Polish | |
| Portuguese | |
| Russian | |
| Spanish | |
| Swedish | |
| Simplified Chinese | |
| Turkish | |
| Traditional Chinese | |
| Regulatory approvals | CE |
| FCC, Class A | |
| RoHS | |
| CB | |
| EAC | |
| EMF | |
| ETL | |
| Warranty | 5-year warranty |
Multimedia Applications
| USB Playback Video | H.263 |
|---|---|
| H.264 | |
| H.265 | |
| MPEG1/2 | |
| MPEG4 | |
| VP8 | |
| VP9 | |
| USB Playback Picture | BMP |
| JPEG | |
| PNG | |
| USB Playback Audio | AAC |
| HEAAC | |
| MPEG |
Interactivity
| Multi-touch technology | 0-gap Infrared touch |
|---|---|
| Touch points | 20 simultaneous touch points |
| Plug and play | HID compliant |
| Protection glass | Anti-Glare |
| Tempered safety glass 7 MOHS | |
| Blue light filter |
Internal Player
| CPU | MTK 9970A |
|---|---|
| Memory | 4 GB RAM |
| Storage | 32 GB eMMc |
| Wi-Fi | 2G/5G/6G 2T2R |
Dimensions
| Set Width | 1494.3 |
|---|---|
| Set Height | 883.2 |
| Set Depth | 99.5 mm(D_Max)/78.5 mm(D_Wallmount) |
| Set Width (inch) | 58.83 |
| Set Height (inch) | 34.77 |
| Set Depth (inch) | 3.92 (D_Max)/3.09(D_Wallmount) |
| Wall Mount | 400 x 400 mm, M8 |
| Bezel width | 17.8 mm(T/R/L) x 31.7 mm(B) |
| Smart Insert mount | 100 x 100 mm, 6xM4L6 |
| Weight | 44.26 |
Weight
| Product with packaging (kg) | 53.8 |
|---|---|
| Product with packaging (lb) | 118.61 |
| Product without stand (kg) | 44.26 |
| Product without stand (lb) | 97.58 |
