B-Line

70BFL2214/12

Boost productivity. Philips B-Line seamlessly integrates into corporate systems for efficient control. Chromecast built-in ensures that presentations run smoothly with instant wireless media sharing from Windows, Apple and Android™ devices.

Get a quote

Technical Specifications

Design

Colour	Anthracite Grey

Audio

Sound output Power	20 (2x10) W
External speaker out	1.5 W Mono 8 Ohm
Speakers	2.0
	Down Firing
Sound Features	DTS-HD
	Dolby Atmos Compatible
	Dolby MS12D
	AC-4
	DTS Studio Sound

Accessories

Optional	Setup RC 22AV9574A/12
Included	Remote Control 22AV1905A/12
	2 x AAA batteries
	Power Cord
	RJ48 to DB9 adapter

Corporate Features

Wired Presentations	Auto Input Selection
	Auto Power ON
	Auto Power OFF
Signage Functions	CMND&Create
	Scheduler
	Banners
Control	Crestron Connected (v2)
	Extron
	Neets
	SICP over IP
Wireless Presentations	Chromecast built in
	Secure Sharing
	Network-managed Sharing
Customisable	Home Screen
	Location Name
	Device Name

Professional TV Features

Professional Mode	Switch-ON Settings Control
	Installation Menu Lock
	Menu Lock
	Volume Limitation
Convenience	Google Assistant*
	Google Account Login
	>40 Supported Menu Languages
	Weather Forecast
Safety	Double Isolation Class II
	Flame Retardant
Control	CMND IP Remote Management
	JEDI Android API Control
	JAPIT HTML5 Control
	AppControl

Tuner/Reception/Transmission

Analogue TV	PAL
IP Playback	Multicast
	Unicast
	HLS
	OTT App Channels
Digital TV	DVB-T/T2/C
	HEVC UHD (up to 2160p60)

Wireless Connectivity

Wireless LAN	802.11 ac
	Wi-Fi-Direct

Connectivity Bottom

External speaker out	Mini-Jack
Antenna	IEC-75
USB 2	USB 2.0
External Control	RJ-48
Ethernet (LAN)	RJ-45
External power	12 V, max 1.5 A
HDMI 3	HDMI 2.0 with HDCP 2.2
HDMI 2	HDMI 2.0 with HDCP 2.2

Power

Energy Label Class	F
Power Saving Features	Eco mode
	Auto switch-off timer
	Light sensor
Standby power consumption	<0.3 W
EU Energy Label power	100 W
Mains power	AC 220-240 V; 50-60 Hz
EPREL registration number	935914
Ambient temperature	0 °C to 40 °C

Dimensions

Set Depth	68/85 mm
Set Height	877 mm
Set Width	1572 mm
Wall-mount compatible	M8
	300 x 300 mm
Product weight	24.6 kg

Supported Display Resolution

HDMI	Up to 3840 x 2160p@60 Hz
USB, LAN	HEVC: up to 3840 x 2160@60 Hz
	Others: up to 1920 x 1080p@60 Hz
Tuner	T2 HEVC: up to 3840 x 2160@60 Hz
	Others: up to 1920 x 1080p@60 Hz

Picture/Display

Contrast ratio (typical)	5000:1
Diagonal screen size (metric)	177 cm
Brightness	350 cd/m²
Operation Mode	Landscape
	16/7
Diagonal screen size (inch)	70 inch
Panel resolution	3840 x 2160p
Display	4K Ultra HD LED

Side Connectivity

Common Interface Slot	CI+ 1.3.2
HDMI1	HDMI 2.0 with HDCP 2.2
USB1	USB 3.0
Headphone out	Mini-Jack

Android TV

Pre-installed apps	YouTube
	Google Play Store*
	Google Play Movies
	Google Play Games
	YouTube Music
Memory size (Flash)	16 GB*
OS	Android TV™ 9 (Pie)

Multimedia

Music formats supported	MP3
	AAC
	WAV
	WMA (v2 up to v9.2)
	WMA-PRO (v9 and v10)
Subtitle formats supported	SRT
	SMI
	TXT
Picture formats supported	JPG
	PNG
	BMP
	GIF
Video playback supported	Formats: H.264/MPEG4 AVC
	MPEG1
	MPEG2
	MPEG4
	WMV9/VC1
	HEVC
	Containers: AVI, MKV
	VP9

Connectivity Enhancements

HDMI	ARC (all ports)
	Auto Input Selection
EasyLink (HDMI CEC)	One touch play
	System Standby
	RC pass through
	system audio control
RJ48	IR-In/Out
	Serial Xpress interface
