MediaSuite

65HFL5214U/27

Designed for a fast-paced world, MediaSuite features advanced connectivity and versatile configuration settings. Chromecast built-in makes streaming fast and easy, while Android™ and Google Play Store unleash infinite possibilities.

Get a quote

Technical Specifications

Design

Colour	Black

Audio

Speakers	2.0
	Down Firing
Sound output Power	20 (2x10) W
Sound Features	DTS-HD
	Dolby Atmos Compatible
	Dolby MS12D
	AC-4
	DTS Studio Sound
External speaker out	1.5W Mono 8 Ohm

Green Specifications

Energy Star	Yes

Accessories

Included	Remote Control 22AV2005B/00
	2x AAA batteries
	Power Cord
	Warranty Leaflet
	Edge Stand
Optional	Voice RC 22AV2025B/00
	Hygenic RC 22AV2226A
	DOCSIS Cable Modem 22AV1970A
	Setup RC 22AV9574A/12

Wireless Connectivity

Wireless LAN	802.11 ac
	Wifi-Direct

Tuner/Reception/Transmission

Analog TV	NTSC
Digital TV	8VSB ATSC; 256QAM Cable
IP Playback	Multicast
	Unicast
	HLS
	OTT App Channels

Connectivity Bottom

HDMI3	HDMI 2.0 with HDCP 2.2
HDMI4	HDMI 2.0 with HDCP 2.2
Ethernet (LAN)	RJ-45
External power	12V, max 1.5A
Digital Audio out	Optical
Antenna	F-Type
External speaker out	Mini-Jack
USB2	USB 2.0

Power

Power Saving Features	Eco mode
	Auto switch-off timer
	Light sensor
Ambient temperature	0°C to 40°C (32°F to 104°F)
Mains power	AC 110-240V; 50-60Hz
Maximum Power Consumption	220 W
Standby power consumption	<0.5 W

Dimensions

Product weight (+stand) (lb)	39.3 lb
Set height (with stand) (inch)	34.12 inch
Product weight (lb)	38.8 lb
Set depth (with stand) (inch)	11.39 inch
Set Height (inch)	32.94 inch
Set width (with stand) (inch)	56.94 inch
Set Depth (inch)	2.65/3.01 inch
Wall mount compatible	300 x 300 mm
	M6
Set Width (inch)	56.94 inch

Supported Display Resolution

HDMI	Up to 3840x2160p@60Hz
USB, LAN	HEVC: up to 3840x2160@60Hz
	Others: up to 1920x1080p@60Hz

Picture/Display

Brightness	340 nit
Diagonal screen size (inch)	65 inch
Display	4K Ultra HD LED
Panel resolution	3840x2160p

Healthcare features

Control	Multi-Remote Control
Convenience	TalkBack
	Independent main speaker mute
Safety	Double isolation class II
	Flame retardant

Android TV

OS	Android TV™ 9 (Pie)
Memory size(Flash)	16GB*
Pre-installed apps	Netflix*
	YouTube
	Google Play Store*
	Google Play Movies
	Google Play Games
	YouTube Music

Connectivity Side

Headphone out	Mini-Jack
HDMI1	HDMI 2.0 with HDCP 2.2
External Control	RJ-12
USB1	USB 3.0
HDMI2	HDMI 2.0 with HDCP 2.2

Hospitality Features

Power control	Quick Start Mode
	Auto Power ON
	Auto Power OFF
CMND&Check-In	Guest Name
	Guest Language
	Messages
	Bill on TV
	Express Checkout
Interactive DRM	VSecure
	Playready Smoothstreaming
	Securemedia
	Pro:Idiom
Sharing	Chromecast Ultra built-in
	Secure Sharing
	Network-managed Sharing
Revenue generation	MyChoice
Remote Control	Low Battery Detection
	RC Battery Door Lock
	Glow-in-the-Dark Clock button
Hotel mode	Switch-ON Settings Control
	Volume limitation
	Installation Menu Lock
	Menu lock
	Joystick Control Lock
	Prison mode
Your brand	Customizable Home Screen
	Customizable Welcome App
	Location Name (Geonames ID)
	CMND&Create
	Custom Dashboard (HTML&APK)
Convenience	Google Assistant*
	Google Account Login
	Weather Forecast
	>40 Supported Menu Languages
	Clock in OFF mode
	Theme TV
	Wake Up Alarm
	Sleep Timer
Control	AppControl
	JEDI Native Android TV Control
	JSON API for TV Control-JAPIT
	Crestron Connected
	Joystick
CMND&Control	Off-Line Channel Editor
	Off-Line Settings Editor
	Remote Management over IP/RF
	TV Group management
	Local Updates via USB
	Instant Initial Cloning

Multimedia

Video playback supported	Formats: H.264/MPEG4 AVC
	MPEG1
	MPEG2
	MPEG4
	WMV9/VC1
	HEVC
	Containers: AVI, MKV
	VP9
Subtitle formats supported	SRT
	SMI
	TXT
Picture formats supported	JPG
	PNG
	BMP
	GIF
Music formats supported	MP3
	AAC
	WAV
	WMA (v2 up to v9.2)
	WMA-PRO (v9 and v10)
