Technical Specifications
Picture/Display
| Display | 4K Ultra HD LED |
|---|---|
| Diagonal screen size (inch) | 50 |
| Panel resolution | 3840x2160p |
| Brightness | 350 |
Audio
| Sound output Power | 20 (2x10) |
|---|---|
| Speakers | 2.0 |
| Down Firing | |
| Bathroom speaker out | 1.5W Mono 8Ohm |
| Sound Features | DTS-HD |
| Dolby Atmos Compatible | |
| Dolby MS12D | |
| AC-4 | |
| DTS Studio Sound |
Design
| Colour | Black |
|---|
Android TV
| Memory size(Flash) | 16GB* |
|---|---|
| OS | Android TV™ 9 (Pie) |
| Pre-installed apps | Netflix* |
| YouTube | |
| Google Play Store* | |
| Google Play Movies | |
| Google Play Games | |
| YouTube Music |
Tuner/Reception/Transmission
| IP Playback | Multicast |
|---|---|
| Unicast | |
| HLS | |
| OTT App Channels | |
| Analog TV | NTSC |
| Digital TV | 8VSB ATSC; 256QAM Cable |
Wireless Connectivity
| Wireless LAN | 802.11 ac |
|---|---|
| Wifi-Direct |
Connectivity Side
| External Control | RJ-12 |
|---|---|
| USB1 | USB 3.0 |
| Headphone out | Mini-Jack |
| HDMI1 | HDMI 2.0 with HDCP 2.2 |
| HDMI2 | HDMI 2.0 with HDCP 2.2 |
Connectivity Bottom
| Ethernet (LAN) | RJ-45 |
|---|---|
| Antenna | F-Type |
| External power | 12V, max 1.5A |
| Digital Audio out | Optical |
| Bathroom speaker out | Mini-Jack |
| USB2 | USB 2.0 |
| HDMI4 | HDMI 2.0 with HDCP 2.2 |
| HDMI3 | HDMI 2.0 with HDCP 2.2 |
Connectivity Enhancements
| HDMI | ARC (all ports) |
|---|---|
| Auto Input Selection | |
| EasyLink (HDMI CEC) | One touch play |
| System Standby | |
| RC pass through | |
| system audio control | |
| RJ12 | SmartPlug Xpress |
Hospitality Features
| Sharing | Chromecast Ultra built-in |
|---|---|
| Secure Sharing | |
| Network-managed Sharing | |
| Your brand | Customizable Home Screen |
| Customizable Welcome App | |
| Location Name (Geonames ID) | |
| CMND&Create | |
| Custom Dashboard (HTML&APK) | |
| Convenience | Google Assistant* |
| Google Account Login | |
| Weather Forecast | |
| >40 Supported Menu Languages | |
| Clock in OFF mode | |
| Theme TV | |
| Wake Up Alarm | |
| Sleep Timer | |
| CMND&Control | Off-Line Channel Editor |
| Off-Line Settings Editor | |
| Remote Management over IP/RF | |
| TV Group management | |
| Local Updates via USB | |
| Instant Initial Cloning | |
| CMND&Check-In | Guest Name |
| Guest Language | |
| Messages | |
| Bill on TV | |
| Express Checkout | |
| Remote Control | Low Battery Detection |
| RC Battery Door Lock | |
| Glow-in-the-Dark Clock button | |
| Control | AppControl |
| JEDI Native Android TV Control | |
| JSON API for TV Control-JAPIT | |
| Serial Xpress Protocol | |
| Crestron Connected | |
| Joystick | |
| Interactive DRM | VSecure |
| Playready Smoothstreaming | |
| Securemedia | |
| Pro:Idiom | |
| Power control | Quick Start Mode |
| Auto Power ON | |
| Auto Power OFF | |
| Revenue generation | MyChoice |
| Hotel mode | Switch-ON Settings Control |
| Volume limitation | |
| Installation Menu Lock | |
| Menu lock | |
| Joystick Control Lock | |
| Prison mode |
Healthcare features
| Control | Multi-Remote Control |
|---|---|
| Nurse call system compatible | |
| Convenience | TalkBack |
| Independent main speaker mute | |
| Safety | Double isolation class II |
| Flame retardant |
Multimedia
| Video playback supported | Formats: H.264/MPEG4 AVC |
|---|---|
| MPEG1 | |
| MPEG2 | |
| MPEG4 | |
| WMV9/VC1 | |
| HEVC | |
| Containers: AVI, MKV | |
| VP9 | |
| Subtitle formats supported | SRT |
| SMI | |
| TXT | |
| Music formats supported | MP3 |
| AAC | |
| WAV | |
| WMA (v2 up to v9.2) | |
| WMA-PRO (v9 and v10) | |
| Picture formats supported | JPG |
| PNG | |
| BMP | |
| GIF |
Supported Display Resolution
| HDMI 1/2 | Up to 3840x2160p @60Hz |
|---|---|
| HDMI 3/4 | Up to 3840x2160p @30Hz |
| USB, LAN | HEVC: up to 3840x2160@60Hz |
| Others: up to 1920x1080p@60Hz | |
| Tuner | up to 1920x1080@60 Hz |
Accessories
| Included | Tabletop Swivel stand |
|---|---|
| Remote Control 22AV2005B/00 | |
| 2x AAA batteries | |
| Power Cord | |
| Warranty Leaflet | |
| Optional | Voice RC 22AV2025B/00 |
| DOCSIS Cable Modem 22AV1970A | |
| Setup RC 22AV9574A/12 |
Power
| Mains power | AC 120-240V; 50-60Hz |
|---|---|
| Standby power consumption | <0.4W |
| Power Saving Features | Eco mode |
| Ambient temperature | 0°C to 40°C (32°F to 104°F) |
| Maximum Power Consumption | 156 |
| Power consumption (typical) | 73 |
Dimensions
| Set Width (inch) | 44.1 |
|---|---|
| Set Height (inch) | 25.6 |
| Set Depth (inch) | 2.4/3.1 |
| Set width (with stand) (inch) | 44.1 |
| Set height (with stand) (inch) | 26.8 |
| Set depth (with stand) (inch) | 9.5 |
| Product weight (lb) | 29.81 |
| Product weight (+stand) (lb) | 35.38 |
| Wall mount compatible | M6 |
| 300 x 200 mm |
