E-Line
This interactive display, powered by Android 13, has up to 40 touchpoints, maximising engagement and collaboration. Toughened anti-glare, anti-reflection and anti-fingerprint glass are ideal for heavy daily use in busy environments.
Features
Technical Specifications
Operating conditions
| Humidity range (operation)[RH] | 20 ~ 80% (without condensation) |
|---|---|
| MTBF | 50,000 hour(s) |
| Humidity range (storage) [RH] | 5 ~ 95% (without condensation) |
| Altitude | 0 ~ 3000 m |
| Temperature range (storage) | -20 ~ 60 °C |
| Temperature range (operation) | 0 ~ 40 °C |
Miscellaneous
| On-Screen Display Languages | Arabic |
|---|---|
| Dutch | |
| Danish | |
| English | |
| French | |
| Finnish | |
| German | |
| Italian | |
| Japanese | |
| Norwegian | |
| Polish | |
| Portuguese | |
| Russian | |
| Spanish | |
| Swedish | |
| Simplified Chinese | |
| Turkish | |
| Traditional Chinese | |
| Warranty | 5 year warranty |
| Regulatory approvals | CE |
| FCC, Class A | |
| RoHS | |
| CB | |
| EAC | |
| EMF | |
| ETL |
Weight
| Product with packaging (kg) | 42.8 kg |
|---|---|
| Product without stand (lb) | 76.50 lb |
| Product with packaging (lb) | 94.36 lb |
| Product without stand (kg) | 34.7 kg |
Picture/Display
| Contrast ratio (typical) | 1200:1 |
|---|---|
| Viewing angle (vertical) | 178 degree |
| Picture enhancement | 3/2 - 2/2 motion pull down |
| 3D Combfilter | |
| Motion compens. deinterlacing | |
| Progressive scan | |
| 3D MA deinterlacing | |
| Dynamic contrast enhancement | |
| Response time (typical) | 8 ms |
| Viewing angle (horizontal) | 178 degree |
| Diagonal screen size (inch) | 64.5 inch |
| Operating system | Android 13 |
| Aspect ratio | 16:9 |
| Dynamic contrast ratio | 500,000:1 |
| Optimum resolution | 3840 x 2160 @ 60 Hz |
| Display colors | 1.07 Billion |
| Diagonal screen size (metric) | 163.9 cm |
| Panel resolution | 3840 x 2160 |
| OS UI resolution | 3840 x 2160 @ 60 Hz |
| Brightness | 400 cd/m² |
| Pixel pitch | 0.372 x 0.372 mm |
| Panel technology | ADS |
Supported Display Resolution
| Computer formats | 800 x 600, 56, 60, 72, 75Hz |
|---|---|
| 848 x 480, 60Hz | |
| 1024 x 768, 60, 70, 75, 85Hz | |
| 1152 x 864, 75Hz | |
| 1280 x 960, 60, 85Hz | |
| 1280x1024, 60,67,75Hz | |
| 1360 x 768, 60Hz | |
| 1366 x 768, 60Hz | |
| 1600 x 1200, 60Hz | |
| 1920 x 1080, 60Hz | |
| 1920 x 1200, 60Hz | |
| 3840 x 2160, 24,25,30,60Hz | |
| Video formats | 480p, 60Hz |
| 720p, 50, 60Hz | |
| 1080i, 50, 60Hz | |
| 1080p, 50, 60Hz | |
| 2160p, 50, 60Hz | |
| 480i, 60Hz |
Interactivity
| Touch points | 40 simultaneous touch points |
|---|---|
| Protection glass | Anti-Glare |
| Tempered safety glass 7MOHS | |
| Blue light filter | |
| Multi-touch technology | 0-gap Infrared touch |
| Plug and play | HID compliant |
Connectivity
| Other connections | OPS |
|---|---|
| USB-B (x2) | |
| Micro USB (x1) (OTG) | |
| Bluetooth | 5.2 BLE |
| Audio output | 3.5 mm Mini Jack (x1) |
| Video input | HDMI 2.0 (x3) |
| USB 3.0 ( x2) | |
| USB 2.0 (x1) | |
| USB-C (up to 65W) | |
| USB-C | |
| Audio input | 3.5 mm mini jack (x1) |
| External control | IR (in/out) 3.5 mm jack |
| RS232C (in/out) 2.5 mm jack | |
| Gb LAN x2 | |
| Video output | HDMI 2.0 (x1) |
Convenience
| Remote control signal | Lockable |
|---|---|
| Screen saving functions | Pixel Shift, Low Brightness |
| Other convenience | Carrying handles |
| NFC | |
| Bluetooth | |
| Placement | Landscape (18/7) |
| Signal loop through | RS232 |
| IR Loopthrough | |
| Network controllable | RS232 |
| RJ45 | |
| Keyboard control | Lockable |
Accessories
| Included Accessories | Philips logo (x1) |
|---|---|
| Quick start guide (x1) | |
| USB A to B cable (3m) (x1) | |
| AC Power Cord | |
| AC switch cover & Screw x1 | |
| Cleaning cloth (x1) | |
| HDMI cable (1.8 m) (x1) | |
| Remote control & AAA batteries | |
| Touch Pen (x2) | |
| Optional accessories | Pen tray with 3x color stylus and eraser |
Dimensions
| Set Width | 1492.02 mm |
|---|---|
| Set Height | 892.28 mm |
| Wall Mount | 500x400mm,M8 |
| Bezel width | 16.7mm(T/R/L), 41.9mm(B) |
| Set Height (inch) | 35.13 inch |
| Set Depth | 116.15 mm |
| Set Width (inch) | 58.74 inch |
| Set Depth (inch) | 4.57 inch |
Internal Player
| Storage | 32 GB eMMc |
|---|---|
| GPU | Multi-Core Mali-G52 |
| Memory | 8GB |
| Wifi | 2T/2R 2.4/5/6 GHz |
| CPU | 4xA73 + 4xA53 |
Sound
| Built-in speakers | 2 x20 W |
|---|
Power
| Standby power consumption | <0.5W |
|---|---|
| Mains power | 100 ~ 240 VAC, 50 ~ 60 Hz |
| Consumption (Typical) | 132 W |
| Power Saving Features | Smart Power |
| Energy Label Class | G. EPEAT Silver. |
Multimedia Applications
| USB Playback Video | H.263 |
|---|---|
| H.264 | |
| H.265 | |
| MPEG1/2 | |
| MPEG4 | |
| VP8 | |
| VP9 | |
| USB Playback Picture | BMP |
| JPEG | |
| PNG | |
| WEBP | |
| USB Playback Audio | AAC |
| HEAAC | |
| MPEG |
