E-Line

65BDL4152E/00

This interactive display, powered by Android 13, has up to 40 touchpoints, maximising engagement and collaboration. Toughened anti-glare, anti-reflection and anti-fingerprint glass are ideal for heavy daily use in busy environments.

Features

Technical Specifications

Operating conditions

MTBF 50,000 hour(s)
Humidity range (storage) [RH] 5 ~ 95% (without condensation)
Humidity range (operation)[RH] 20 ~ 80% (without condensation)
Altitude 0 ~ 3000 m
Temperature range (storage) -20 ~ 60 °C
Temperature range (operation) 0 ~ 40 °C

Weight

Product without stand (lb) 76.50 lb
Product with packaging (kg) 42.8 kg
Product with packaging (lb) 94.36 lb
Product without stand (kg) 34.7 kg

Picture/Display

Contrast ratio (typical) 1200:1
Viewing angle (vertical) 178 degree
Viewing angle (horizontal) 178 degree
Response time (typical) 8 ms
Picture enhancement 3/2 - 2/2 motion pull down
3D Combfilter
Motion compens. deinterlacing
Progressive scan
3D MA deinterlacing
Dynamic contrast enhancement
Operating system Android 13
Dynamic contrast ratio 500,000:1
Diagonal screen size (inch) 64.5 inch
Aspect ratio 16:9
Optimum resolution 3840 x 2160 @ 60 Hz
Display colors 1.07 Billion
Diagonal screen size (metric) 163.9 cm
OS UI resolution 3840 x 2160 @ 60 Hz
Panel resolution 3840 x 2160
Brightness 400 cd/m²
Pixel pitch 0.372 x 0.372 mm
Panel technology ADS

Miscellaneous

On-Screen Display Languages Arabic
Dutch
Danish
English
French
Finnish
German
Italian
Japanese
Norwegian
Polish
Portuguese
Russian
Spanish
Swedish
Simplified Chinese
Turkish
Traditional Chinese
Regulatory approvals CE
FCC, Class A
RoHS
CB
EAC
EMF
ETL
Warranty 5 year warranty

Supported Display Resolution

Computer formats 800 x 600, 56, 60, 72, 75Hz
848 x 480, 60Hz
1024 x 768, 60, 70, 75, 85Hz
1152 x 864, 75Hz
1280 x 960, 60, 85Hz
1280x1024, 60,67,75Hz
1360 x 768, 60Hz
1366 x 768, 60Hz
1600 x 1200, 60Hz
1920 x 1080, 60Hz
1920 x 1200, 60Hz
3840 x 2160, 24,25,30,60Hz
Video formats 480p, 60Hz
720p, 50, 60Hz
1080i, 50, 60Hz
1080p, 50, 60Hz
2160p, 50, 60Hz
480i, 60Hz

Interactivity

Touch points 40 simultaneous touch points
Protection glass Anti-Glare
Tempered safety glass 7MOHS
Blue light filter
Multi-touch technology 0-gap Infrared touch
Plug and play HID compliant

Connectivity

Audio output 3.5 mm Mini Jack (x1)
Bluetooth 5.2 BLE
Other connections OPS
USB-B (x2)
Micro USB (x1) (OTG)
Video input HDMI 2.0 (x3)
USB 3.0 ( x2)
USB 2.0 (x1)
USB-C (up to 65W)
USB-C
Audio input 3.5 mm mini jack (x1)
External control IR (in/out) 3.5 mm jack
RS232C (in/out) 2.5 mm jack
Gb LAN x2
Video output HDMI 2.0 (x1)

Convenience

Remote control signal Lockable
Screen saving functions Pixel Shift, Low Brightness
Other convenience Carrying handles
NFC
Bluetooth
Network controllable RS232
RJ45
Placement Landscape (18/7)
Keyboard control Lockable
Signal loop through RS232
IR Loopthrough

Accessories

Included Accessories Philips logo (x1)
Quick start guide (x1)
USB A to B cable (3m) (x1)
AC Power Cord
AC switch cover & Screw x1
Cleaning cloth (x1)
HDMI cable (1.8 m) (x1)
Remote control & AAA batteries
Touch Pen (x2)
Optional accessories Pen tray with 3x color stylus and eraser

Dimensions

Set Height 892.28 mm
Set Width 1492.02 mm
Wall Mount 500x400mm,M8
Set Depth 116.15 mm
Set Width (inch) 58.74 inch
Bezel width 16.7mm(T/R/L), 41.9mm(B)
Set Height (inch) 35.13 inch
Set Depth (inch) 4.57 inch

Internal Player

GPU Multi-Core Mali-G52
Storage 32 GB eMMc
Wifi 2T/2R 2.4/5/6 GHz
Memory 8GB
CPU 4xA73 + 4xA53

Sound

Built-in speakers 2 x20 W

Power

Standby power consumption <0.5W
Mains power 100 ~ 240 VAC, 50 ~ 60 Hz
Power Saving Features Smart Power
Consumption (Typical) 132 W
Energy Label Class G. EPEAT Silver.

Multimedia Applications

USB Playback Picture BMP
JPEG
PNG
WEBP
USB Playback Video H.263
H.264
H.265
MPEG1/2
MPEG4
VP8
VP9
USB Playback Audio AAC
HEAAC
MPEG
