P-Line

65BDL6017P/00

Outperform in challenging environments with the robust 24/7 Philips Signage 6000 Series. With enhanced brightness up to 800 nits and an option to add Philips Wave remote management, ideal for kitchens through to transport hubs and beyond.

Get a quote

Technical Specifications

Connectivity

Audio input	3.5 mm jack
External control	IR (in/out) 3.5 mm jack
	RJ45
	RS232C (in/out) 2.5 mm jack
	Ambient Light Sensor
Video output	DisplayPort 1.2 (x 1)
	HDMI 2.0 (x 1)
Video input	Display Port1.2 (x 1)
	DVI-I (x 1)
	HDMI 2.0 (x 3)
Audio output	3.5 mm jack
Other connections	USB 2.0 (x 2)
	OPS
	Thermal sensor

Convenience

Network controllable	RS232
	RJ45
Tiled Matrix	Up to 15 x 15
Energy-saving functions	Smart Power
Placement	Landscape (24/7)
	Portrait (24/7)
Screen-saving functions	Pixel Shift, Low Bright
Ease of installation	Carrying Handles
	Conformal Coating
Signal loop through	DisplayPort
	RS232
	HDMI
	IR Loop through

Accessories

Stand	BM05922(optional)
Included Accessories	AC Switch Cover
	Philips logo (x 1)
	Power cable (x 3)
	Quick start guide (x 1)
	Remote control and AAA batteries
	RS232 cable (3 m) (x 1)
	RS232 daisy chain cable (x 1)
	USB Cover (x 1)

Dimensions

Product weight	27.8 kg
Product weight (lb)	61.3 lb
Bezel width	14.90 mm (Even bezel)
Set Depth (inch)	3.54 inch (at handle),2.72 (at wall mount) inch
Set Depth	89.90 mm (at handle), 69.0 mm (at wall mount) mm
Set Width	1462.3 mm
Set Width (inch)	57.71 inch
Wall Mount	400 x 400 mm, M8
Set Height	837.3 mm
Set Height (inch)	32.96 inch

Sound

Built-in speakers	2 x 10 W RMS

Power

Mains power	100 ~ 240 VAC, 50 ~ 60 Hz
Consumption (Max)	210 W
Consumption (Typical)	128 W
Energy Label Class	G
Standby power consumption	<0.5 W

Multimedia Applications

USB Playback Picture	BMP
	JPEG
	PNG
USB Playback Video	H.264
	H.265
	Motion JPEG
	MPEG1/2
	WMV3
USB Playback Audio	AAC
	MPEG
	HEAAC

Miscellaneous

Regulatory approvals	CE
	FCC, Class A
	CB
	BSMI
	EAC
	EMF
	VCCI
	PSB
	Energy Star 8.0
	ETL
	EPA
On-Screen Display Languages	Arabic
	Dutch
	Danish
	English
	French
	Finnish
	German
	Italian
	Japanese
	Norwegian
	Polish
	Portuguese
	Russian
	Spanish
	Swedish
	Simplified Chinese
	Turkish
	Traditional Chinese
Warranty	3 year warranty

Operating conditions

Temperature range (storage)	-20 ~ 60 °C
MTBF	50,000 hour(s)
Humidity range (operation)[RH]	20~80% RH (No condensation)
Temperature range (operation)	0 ~ 40 °C
Humidity range (storage) [RH]	5~95% RH (No condensation)
Altitude	0 ~ 5000 m
Ingress protection	IP5X

Picture/Display

Panel technology	ADS
Response time (typical)	8 ms
Pixel pitch	0.372 x 0.372 mm
Panel resolution	3840 x 2160
Viewing angle (horizontal)	178 degree
Dynamic contrast ratio	500,000:1
Aspect ratio	16:9
Display colours	1.07 billion
Optimum resolution	3840 x 2160 @ 60 Hz
Brightness	800 cd/m²
Diagonal screen size (metric)	164 cm
Diagonal screen size (inch)	64.5 inch
Viewing angle (vertical)	178 degree
Contrast ratio (typical)	1200:1
Haze	25%

Supported Display Resolution

Computer formats	640 x 480, 60, 67, 72, 75 Hz
	720 x 400, 70 Hz
	800 x 600, 56, 60, 72, 75 Hz
	1024 x 768, 60, 70, 75 Hz
	1152 x 864, 75 Hz
	1152 x 870, 75 Hz
	1280 x 720, 60 Hz
	1280 x 800, 60 Hz
	1280 x 1024, 60 Hz
	1440 x 900, 60 Hz
	1600 x 1200, 60 Hz
	1680 x 1050, 60 Hz
	1920 x 1080, 60 Hz
Video formats	480p, 60 Hz
	576p, 50 Hz
	720p, 50, 60 Hz
	1080i, 50, 60 Hz
	1080p, 50, 60 Hz
	3840 x 2160, 30Hz
	3840 x 2160, 60 Hz
