P-Line

43BDL6017P/00

Outperform in challenging environments with the robust 24/7 Philips Signage 6000 Series. With enhanced brightness up to 800 nits and an option to add Philips Wave remote management, ideal for kitchens through to transport hubs, and beyond.

Get a quote

Technical Specifications

Connectivity

Other connections	USB 2.0 (x2)
	OPS
	Thermal sensor
Audio input	3.5 mm jack
Video input	Display Port1.2 (x1)
	DVI-I (x 1)
	HDMI 2.0 (x3)
Audio output	3.5mm jack
Video output	DisplayPort 1.2 (x1)
	HDMI 2.0 (x1)
External control	IR (in/out) 3.5 mm jack
	RJ45
	RS232C (in/out) 2.5 mm jack
	Ambient Light Sensor

Convenience

Screen saving functions	Pixel Shift, Low Bright
Ease of installation	Carrying Handles
	Edge Alignment Kit
	Conformal Coating
Tiled Matrix	Up to 15 x 15
Energy saving functions	Smart Power
Signal loop through	DisplayPort
	RS232
	HDMI
	IR Loopthrough
Placement	Landscape (24/7)
	Portrait (24/7)
Network controllable	RS232
	RJ45

Accessories

Included Accessories	AC Switch Cover
	Philips logo (x1)
	Power cable (x3)
	Quick start guide (x1)
	Remote control & AAA batteries
	RS232 cable (3 m) (x1)
	RS232 daisy chain cable (x1)
	USB Cover (x1)
	Edge Alignment Kit (x2)
Stand	BM05922(optional)

Dimensions

Set Width	973 mm
Product weight	14.12 kg
Set Height	561.2 mm
Product weight (lb)	31.13 lb
Set Depth (inch)	3.02 inch (at handle), 2.52 (at wall mount) inch
Wall Mount	200 x 200 mm, M6
Set Height (inch)	22.1 inch
Bezel width	13.9mm (Even bezel)
Set Width (inch)	38.31 inch
Set Depth	76.80 mm (at handle),64.0 (at wall mount) mm

Sound

Built-in speakers	2 x 10W RMS

Power

Standby power consumption	<0.5 W
Consumption (Max)	150 W
Mains power	100 ~ 240 VAC, 50 ~ 60 Hz
Consumption (Typical)	85 W
Energy Label Class	G

Multimedia Applications

USB Playback Picture	BMP
	JPEG
	PNG
USB Playback Audio	AAC
	MPEG
	HEAAC
USB Playback Video	H.264
	H.265
	Motion JPEG
	MPEG1/2
	WMV3

Operating conditions

Humidity range (storage) [RH]	5 ~ 95% RH (No condensation)
Ingress protection	IP5X
Temperature range (storage)	-20 ~ 60 °C
Humidity range (operation)[RH]	20 ~ 80% RH (No condensation)
MTBF	50,000 hour(s)
Altitude	0 ~ 5000 m
Temperature range (operation)	0 ~ 40 °C

Picture/Display

Contrast ratio (typical)	1200:1
Response time (typical)	8 ms
Viewing angle (vertical)	178 degree
Dynamic contrast ratio	500,000:1
Haze	25 %
Aspect ratio	16:9
Panel resolution	3840 x 2160
Diagonal screen size (metric)	108 cm
Display colors	1.07 billion
Viewing angle (horizontal)	178 degree
Brightness	800 cd/m²
Diagonal screen size (inch)	42.5 inch
Optimum resolution	3840 x 2160 @ 60Hz
Pixel pitch	0.2451 x 0.2451 mm
Panel technology	ADS

Miscellaneous

On-Screen Display Languages	Arabic
	Dutch
	Danish
	English
	French
	Finnish
	German
	Italian
	Japanese
	Norwegian
	Polish
	Portuguese
	Russian
	Spanish
	Swedish
	Simplified Chinese
	Turkish
	Traditional Chinese
Warranty	3 year warranty
Regulatory approvals	CE
	FCC, Class A
	CB
	BSMI
	EAC
	EMF
	VCCI
	PSB
	ETL
	EPA

Supported Display Resolution

Computer formats	1440 x 900, 60Hz
	1024 x 768, 60, 70, 75Hz
	1152 x 864, 75Hz
	1152 x 870, 75Hz
	1280 x 1024, 60Hz
	1280 x 720, 60Hz
	1280 x 800, 60Hz
	1600 x 1200, 60Hz
	1680 x 1050, 60Hz
	1920 x 1080, 60Hz
	640 x 480, 60, 67, 72, 75Hz
	720 x 400, 70Hz
	800 x 600, 56, 60, 72, 75Hz
Video formats	480p, 60Hz
	576p, 50Hz
	720p, 50, 60Hz
	1080i, 50, 60Hz
	1080p, 50, 60Hz
	3840 x 2160, 30Hz
	3840 x 2160, 60Hz
