B-Line
B-Line
Dare to B
Powered by Android
Android-powered Philips professional displays are fast, versatile and easy to navigate. All displays are optimized for native Android apps and you can install web apps directly to the display too. Automatic updates ensure apps stay up to date.
Google Cast
Enable instant, secure wireless casting of movies, presentations, and more from smart devices (mobiles, laptops, tablets) in up to 4K resolution. Google Cast is cost-effective, requires no extra hardware, and is secure for professional use. Users simply tap the Google Cast icon on their smart device to start streaming content from thousands of cast-enabled apps—their smart device becomes the remote.
Crestron Connected certified
Integrate this Philips professional display to your Crestron network for full remote control via your laptop, desktop or mobile device. Switch the display on and off, schedule content, manage settings, and easily connect external devices. Crestron Connected® provides a fast, reliable and secure enterprise level solution for wireless and wired content sharing from Apple, Windows, Android and Linux devices.
Google Play Store
Full access to the entire Google Play Store makes it easy to add apps, games, music, movies, and more to your Philips professional display. New business tools and extra entertainment options are added to the catalog daily, ensuring that you always have access to the latest global trends.
HDMI hotplug detection
When wireless connectivity is not an option, HDMI hotplug detection recognizes direct cabled connections from presentation sources and automatically handles source changes and on/off switching.
AppControl
Take full, centralized control of the apps installed on your Philips professional TVs. AppControl lets you install, delete, and manage apps on selected TVs or your entire network so that you can offer personalized experiences to your guests and customers—no matter how many TVs you are managing.
CMND & Control
Run your display network over a local (LAN or RF) connection. CMND & Control allows you to perform vital functions like updating software and settings, as well as monitoring display status. Whether you’re in charge of one TV or more, CMND & Control makes managing your fleet easy.
Scheduler
Built-in scheduler makes it easy to launch content and apps based on time of day for a more engaging environment with better results.
Bright ideas
B-Line inspires brighter ideas with collaborative function.
Features
Technical Specifications
Picture/Display
| Display | 4K Ultra HD LED |
|---|---|
| Diagonal screen size (inch) | 58 |
| Panel resolution | 3840x2160p |
| Brightness | 350 |
| Contrast ratio (typical) | 5000:1 |
| Operation Mode | Landscape |
| 16/7 |
Audio
| Sound output Power | 20 (2x10) |
|---|---|
| Speakers | 2.0 |
| Down Firing | |
| Sound Features | DTS-HD |
| Dolby Atmos Compatible | |
| Dolby MS12D | |
| AC-4 | |
| DTS Studio Sound | |
| External speaker out | 1.5W Mono 8 Ohm |
Design
| Colour | Black |
|---|
Android TV
| Memory size(Flash) | 16GB* |
|---|---|
| OS | Android TV™ 9 (Pie) |
| Pre-installed apps | YouTube |
| Google Play Store* | |
| Google Play Movies | |
| Google Play Games | |
| YouTube Music |
Tuner/Reception/Transmission
| IP Playback | Multicast |
|---|---|
| Unicast | |
| HLS | |
| OTT App Channels | |
| Analog TV | NTSC |
| Digital TV | 8VSB ATSC; 256QAM Cable |
Wireless Connectivity
| Wireless LAN | 802.11 ac |
|---|---|
| Wifi-Direct |
Connectivity Side
| USB1 | USB 3.0 |
|---|---|
| Headphone out | Mini-Jack |
| HDMI1 | HDMI 2.0 with HDCP 2.2 |
| HDMI2 | HDMI 2.0 with HDCP 2.2 |
Connectivity Bottom
| Ethernet (LAN) | RJ-45 |
|---|---|
| Antenna | F-Type |
| External power | 12V, max 1.5A |
| Digital Audio out | Optical |
| External speaker out | Mini-Jack |
| USB2 | USB 2.0 |
| HDMI3 | HDMI 2.0 with HDCP 2.2 |
| HDMI4 | HDMI 2.0 with HDCP 2.2 |
Connectivity Enhancements
| HDMI | ARC (all ports) |
|---|---|
| Auto Input Selection | |
| EasyLink (HDMI CEC) | One touch play |
| System Standby | |
| RC pass through | |
| system audio control |
Corporate Features
| Wired Presentations | Auto Input Selection |
|---|---|
| Auto Power ON | |
| Auto Power OFF | |
| Wireless Presentations | Chromecast built-in |
| Secure Sharing | |
| Network-managed Sharing | |
| Signage Functions | CMND&Create |
| Scheduler | |
| Banners | |
| Control | Crestron Connected (v2) |
| Extron | |
| Customizable | Home Screen |
| Location Name | |
| Device Name |
Professional TV Features
| Professional Mode | Installation Menu Lock |
|---|---|
| Menu Lock | |
| Switch-ON Settings Control | |
| Volume Limitation | |
| Convenience | >40 Supported Menu Languages |
| Google Account Login | |
| Google Assistant* | |
| Weather Forecast | |
| Control | AppControl |
| CMND IP Remote Management | |
| JAPIT HTML5 Control | |
| JEDI Android API Control | |
| Safety | Double Isolation Class II |
| Flame Retardant | |
| DRM | Pro:Idiom |
| VSecure |
Multimedia
| Video playback supported | Formats: H.264/MPEG4 AVC |
|---|---|
| MPEG1 | |
| MPEG2 | |
| MPEG4 | |
| WMV9/VC1 | |
| HEVC | |
| Containers: AVI, MKV | |
| VP9 | |
| Subtitle formats supported | SRT |
| SMI | |
| TXT | |
| Music formats supported | MP3 |
| AAC | |
| WAV | |
| WMA (v2 up to v9.2) | |
| WMA-PRO (v9 and v10) | |
| Picture formats supported | JPG |
| PNG | |
| BMP | |
| GIF |
Supported Display Resolution
| HDMI 1/2 | Up to 3840x2160p @60Hz |
|---|---|
| HDMI 3/4 | Up to 3840x2160p @30Hz |
| USB, LAN | HEVC: up to 3840x2160@60Hz |
| Others: up to 1920x1080p@60Hz | |
| Tuner | up to 1920x1080@60 Hz |
Accessories
| Included | Remote Control 22AV1905A/12 |
|---|---|
| 2x AAA batteries | |
| Power Cord | |
| Optional | Voice RC 22AV2025B/00 |
| Setup RC 22AV9574A/12 |
Power
| Mains power | AC 120-240V; 50-60Hz |
|---|---|
| Standby power consumption | <0.4W |
| Power Saving Features | Eco mode |
| Ambient temperature | 0°C to 40°C (32°F to 104°F) |
| Maximum Power Consumption | 157 |
| Power consumption (typical) | 77 |
Dimensions
| Set Width (inch) | 51.26 |
|---|---|
| Set Height (inch) | 29.92 |
| Set Depth (inch) | 3.19/3.39 |
| Product weight (lb) | 33.29 |
| Wall mount compatible | M6 |
| 300 x 200 mm |
